King KPC ABS FR

King KPC ABS in a FR (flame retardant) formulation for use in applications such as transformer housings, switches, shelving, air conditioner components.
The advantage of King KPC ABS Black FR is that this material combines strength and rigidity of the acrylonitrile and styrene polymers with the toughness of the polybutadiene rubber. A variety of modifications have been made to improve impact resistance, toughness and heat resistance. The impact resistance does not fall off rapidly at low temperatures and stability under load is excellent with limited loads. King KPC ABS Black FR is considered superior for its hardness, gloss, toughness, and electrical insulation properties. KPC ABS Black FR is easily machinable and is available in smaller sizes. It is extensively used in prototyping, the modeling industry and other mechanical applications.
King KPC ABS Black FR is manufactured in our state-of-the-art compression molding system located in North Port, Florida.

General Applications

• Transformer housings
• Switches
• Shelving
• Air conditioning components
• Industrial enclosures

Standard Color           Black

Standard Sheet Sizes: (in)
48” x 96”

Standard Gauge: (in)
1/2”  |  5/8”  | 3/4”  |  1”  | 1-1/4” | 1-1/2” | 1-3/4” | 2” | 2-1/4” | 2-1/2” |  3”

Weight: (lbs)
1o1.5 lbs  |  126.8 lbs | 152.2 lbs  |  202.9 lbs  | 253.7 lbs | 304.4 lbs | 355.2 lbs | 405.9 lbs | 456.6 lbs | 507.4 lbs |  608.8 lbs

Standard Sheet Sizes: (mm)
1219mm x 2438mm

Standard Gauges: ( mm)
12.7mm | 15.87mm |19mm  |  25.4mm  |  31.75mm  | 38.1mm  |  44.45mm | 50.8mm  | 57.15mm | 63.5mm | 76.2mm

Weight: (kg)
46kg  |  57.5kg | 69kg  |  92kg  | 115kg | 138kg | 161kg | 184kg | 207kg | 230kg |  276kg

Tolerance Information:
Gauges 1/2″ through 1-1/4″ can be produced both ± 10% or Plus Only, both width or length at room temperature
Gauges 1-1/2″ and greater is plus only at room temperature

Flammability Rating for KPC ABS FR
________________________________
Flammability    Nominal Value Unit    Test Method
Flame Rating                UL                          UL 94
__________________________________
00.591 in                    V-O
__________________________________
0.0787 in                 • V-O/•5VB
__________________________________
0.0984 in                • V-O/•5VB
__________________________________
0.118 in                   •V-O/•5vB
*All values are determined on specimens prepared according  to ASTM Standards.
Nominal values should not be interpreted as specifications.
King KPC ABS FR is environmentally stablized and RoHS complaint
