King ColorBoard®is a high-density polyethylene sheet that is environmentally stabilized with bright primary colors for use in signage, industrial, marine, playground and recreational applications.
Now Available for Upgrade with King FlameShield for our ASTM E-84 Class A or B Flame/Smoke Compliance and CAN/ULC-S102 for Canadian Compliance
King ColorBoard® is a high density polyethylene sheet that is environmentally stabilized for outdoor use. It’s bright, primary colors make it ideal for sign, industrial, marine, playground and recreational applications. For maximum versatility, standard colors are made to coordinate with King ColorCore®. King ColorBoard® features an attractive matte finish and is manufactured to the highest standards in the industry. Base material are FDA approved as are most pigments. It is made with impact resistant high density polyethylene to handle more abuse than conventional sign and playground materials. ColorBoard is environmentally stablized and will never fade or discolor in direct sunlight. And you never have to worry about delamination, rotting or warping with King ColorBoard®. King ColorBoard® is upgradable with our exclusive antimicrobial additive King MicroShield®. The latest technology for protecting the product surface against a broad spectrum of damaging bacteria, algae, and fungi by reducing the amount of microbes by 99.99% and killing the microbes on contact. See our King MicroShield® page for more information.
Standard Sheet Sizes: (in/mm) Standard Gauge: (in/mm) Weight: (lbs/kg) Tolerance Information: Gauge ± 5%, both width or length Plus Only at room temperature
*All values are determined on specimens prepared according to ASTM Standards. Nominal
FlameShield Physical Properties Sheet | FlameShield MSDS
Protect Your Interests with E-84 Class A or B Flame Rated Polymer Sheets from King Plastic Corporation This test method is intended to compare the surface flame spread and smoke developed measurements to those obtained from the tests of mineral fiber cement board and select grade red oak flooring. The results are expressed as Flame Spread Index and Smoke Developed Index. Results Class B Interior Finish:
*Note: Color accuracy can vary considerably on computer monitors and printers. Please consult your distributor for a product sample before making critical color choices. Specialty colors by special order only. 1 point: MR Credit 2.2 Sustainable Purchasing: Durable Goods 2 points: MR credit 4.2 2 points: MR Credit 4.2 Recycled Content
48″ x 96″ / 1219mm x 2438mm
Custom sizes available
1/4″| 1/2″| 3/4″ | 6.4mm | 12.7mm | 19mm
Custom thicknesses available.
40 lbs | 80 lbs | 120 lbs | 18kg | 36kg | 54kg
Properties
Units
ASTM
Nominal Values
Density
g/cc
D1505
.96
Tensile Strength @ Yield
psi
D638
>4100
Tensile Modulus
psi
D638
225,00
Elongation @ Yield
%
D638
9.8
Elongation @ Break
%
D638
>600
Flexural Modulus
psi
D790
185,000
Flexural Stress @ 5% Strain
psi
D790
3,810
Compressive Properties 10% Strain
psi
D695
4,950
Durometer
Shore D
D2240
68
Tensile Impact
ft.lbs./in.2
D1822
115
Izod Impact Resistance
ft.lbs./in.2
D256
1.1
Brittleness Temp.
ºF
D746
<-105º
Vicat Softening
ºF
D1525
253º
Heat Deflection Temp. 66 psi
ºF
D648
167º
Screw and Nail Withdrawl
lbs
D1761
657 & 63
Flammability
Rating
UL94
HB
values should not be interpreted as specifications.
King ColorBoard® is made entirely from FDA and USDA approved materials
King ColorBoard® meets ASTM D4976 PE235
RoHS Statement
Properties
Units
ASTM
Nominal Values
Density
g/cc
D1505
1.3 – 1.35
Tensile Strength @ Yield
p.s.i.
D638
3780
Tensile Strength @ Break
p.s.i.
D663
1,170
Elongation @ Yield
%
D638
8.6
Elongation @ Break
%
D638
53
Flexural Modulus
p.s.i.
D790
179,000
Durometer (Hardness)
Shore D
D2240
71
Flexural Stress @ 5% Strain
psi
D790
4330
Vicat Softening
ºF
D1525
264
Heat Deflection Temp.
66p.s.i.ºF
D648
188
Coefficient of Linear
Thermal Expansionin./in./ºF
D696
6×10-5
Class A
Class B
Surface Burning Characteristics
FSI & SDI
E-84
20 & 60
20 & 65
Surface Burning Characteristics
FSI & SDI
ULC-S102
20 & 65
20 & 65
Available in King ColorBoard®
The ASTM E84
Class A Interior Finish:
Flame Spread Index 0-25, Smoke Developed Index 0-450. Includes any material classified at 25 or less on the flame spread test scale and 450 or less on the smoke developed test scale. Any element thereof when so tested shall not continue to propagate fire.
Flame Spread Index 26-75, Smoke Developed Index 0-450. Includes any material classified at 25 but not more than 76 on the flame spread test scale and 450 or less on the smoke developed test scale.
ASTM E84 Class A Certification | ASTM E84 Class B Certification
KPG Red, KPG Orange, KPG Blue, KPG Green, KPG Yellow, KPG Tan
LEED for Existing Buildings, September 2008
LEED for New Construction Version 2.2
Recycled ContentLEED for Schools, First Edition November 2007
